New Energy Copper Busbar Bending Machine, Coated Bracket Former, and Camless Spring Coiler – GT40‑12R for EV & ESS Applications
The GT40-12R is a heavy-duty camless spring coiler / bending machine engineered specifically for the new energy industry. It excels in precision bending of copper busbars and coated copper busbar brackets. With its camless drive technology, 21.8kW high‑power motor, robust rigidity, and fast tool changeover, it is ideally suited for high‑volume, consistent production of busbar connectors and bracket components for EV and energy storage systems.
Product Description
-
Innovative Camless Structure
Replaces traditional cams with servo‑driven direct transmission, reducing mechanical wear, improving bending angle accuracy, and shortening setup time by over 30%. -
New‑Energy‑Oriented Application
Optimized for copper busbar and coated bracket bending; supports quick die change for multi‑variety, small‑batch production – perfect for busbar connectors and battery module supports. -
High‑Power Drive System
Equipped with a 21.8kW efficient motor, delivering stable torque to process copper bars up to 6mm thick and 80mm wide, satisfying heavy‑duty bending requirements. -
Compact Heavy‑Duty Frame
Dimensions: 2750×1600×1920mm; net weight 4.1 tons. High‑rigidity cast bed ensures long‑term precision and stability under continuous heavy loads. -
Smart Control Interface
Touchscreen panel with parameter memory for up to hundreds of bending programs; supports remote diagnostics and online upgrades, reducing operator dependency. -
Customization Service
Non‑standard designs available based on customer workpiece dimensions and die requirements. Unified order/item number (20221226) for easy traceability and management.
FAQ
| Question | Answer |
|---|---|
| What is the minimum order quantity? | One unit minimum; volume orders receive tiered discounts. |
| What is the delivery time? | Standard models in stock: 7~15 working days after order; custom models: 25~30 working days. |
| What is the warranty period? | 12 months for the whole machine (6 months for electrical parts), with lifelong paid maintenance and spare parts supply. |
| Do you offer installation, commissioning, and training? | Remote video guidance is provided. On‑site service is available upon request (additional cost applies). |
| Can I get free sample bending? | Yes, we accept customer‑supplied copper bars for free trial bending and will provide a forming report; customer only pays round‑trip shipping. |
| What payment methods are accepted? | T/T, L/C, Alipay/WeChat corporate transfer, or other terms negotiable. |
Why Choose US？
-
Deep Industry Expertise – Over 10 years in spring coiler and bending equipment R&D, serving more than 100 new‑energy enterprises.
-
Quality Assured – ISO 9001 and CE certified; core components from top international brands.
-
Fast Response – 24/7 online technical support; 48‑hour on‑site service in major domestic cities, 72‑hour remote support overseas.
-
Flexible Customization – From die design to automated production lines, we provide one‑stop bending solutions to help you reduce costs and increase efficiency.
-
Proven Track Record – Product return rate below 1.5%, customer repurchase rate as high as 92%.
Product Specification Sheet
| Field | Content |
|---|---|
| Order No. | 20221226 |
| Customized | Yes |
| Item No. | 20221226 |
| Model | GT40-12R |
| Application | Bending & forming; new energy connecting copper busbar bender / new energy coated copper busbar bracket bender / camless spring coiler |
| Motor Power | 21.8 (kW) |
| Overall Dimension | 2750×1600×1920 (mm) |
| Weight | 4.1 (t) |
| Type | Camless spring coiler |
