3D CNC Wire Bending Machine Camless Spring Coiler Multi‑Axis Wire Former for Iron & Steel – WG35‑10R in Stock
The WG35‑10R CNC wire bending machine is a high‑precision, multi‑axis metal wire forming system that integrates 3D three‑dimensional bending and camless spring coiling. Designed for complex wire shapes such as lanterns, birdcages, crafts, and industrial components, it employs full‑servo control with a movement speed of 100 m/min and a main motor power of 17.6 kW. The machine handles various materials including iron, stainless steel, and copper wire, making it an ideal upgrade for wire‑product manufacturers seeking efficiency and flexibility.
Product Description
-
Multi‑Axis 3D Forming
Equipped with a 12‑axis wire transfer system, it enables bending at any spatial angle, easily producing intricate shapes for lanterns, birdcages, and industrial brackets. -
Camless Innovative Design
Eliminates traditional cam mechanisms, reducing mechanical wear and setup time by over 50%. Programming is flexible, allowing quick changeovers for small‑batch, high‑mix production. -
High Speed & Productivity
Maximum movement speed of 100 m/min, combined with high‑torque servo motors, significantly shortens idle and cycle times, boosting output per shift. -
Powerful Drive System
A 17.6 kW main motor delivers ample torque for thicker wires and high‑strength materials, ensuring stable operation and precise bending. -
Rugged & Compact Structure
Dimensions: 2200×1600×1860 mm, weight: 2500 kg. The rigid frame minimizes vibration, saves floor space, and suits flexible workshop layouts. -
Intelligent CNC Control
Features an industrial HMI with USB import capability, storing up to thousands of product programs. User‑friendly interface allows quick training for operators. -
Customization Support
Tooling, fixtures, and control logic can be tailored to meet non‑standard wire‑forming requirements, with full technical support throughout the process.
FAQ
Q1: What is the maximum wire diameter this machine can process?
A: It depends on material strength. For mild steel, we recommend up to φ8 mm; for stainless steel, up to φ6 mm. Larger diameters are available upon request for custom models.
Q2: Do you offer free sample processing?
A: We provide sample processing for a fee (deductible from the final order). Send your drawing or sample, and we will return the bent sample within 3 working days.
Q3: What is the lead time and payment terms?
A: Standard lead time is 30 working days after deposit. Payment: 30% upfront + 70% before shipment, via T/T or L/C.
Q4: Is installation, commissioning, and training included?
A: Yes. We dispatch an engineer for on‑site setup, operator training, and maintenance guidance. Remote video support is also available.
Q5: What is the warranty period and after‑sales response time?
A: One‑year comprehensive warranty (extendable for key components). Service response within 2 hours, and on‑site arrival within 48 hours (for major domestic cities in China).
Q6: Is the system compatible with CAD/CAM software?
A: Yes. It reads common formats like DXF and IGES, and we supply offline programming software for complex path design.
Why Choose US？
Product Specification Sheet
| Item | Details |
|---|---|
| Custom Processing | Yes |
| Article No. | 0019 |
| Type | Metal Wire Bending Machine |
| Model | WG35-10R |
| Application Scope | Lantern & birdcage iron wire bender; 3D CNC 3-axis wire bending machine; camless spring machine |
| Also Known As | CNC Wire Bending Machine |
| Dimensions (mm) | 2200 × 1600 × 1860 |
| Weight (kg) | 2500 |
| Main Motor Power | 17.6 kW |
| Movement Speed | 100 m/min |
| Specification | WG35-12-axis wire transfer machine |
