Custom 261kWh Industrial Commercial Liquid-Cooled BESS Solar Battery Storage Cabinet Manufacturer
The GSL-BESS-261K is a high-performance lithium iron phosphate (LFP) energy storage system specifically designed for commercial and industrial (C&I) applications. With a nominal capacity of 261.2 kWh, a standard voltage of 832 V, and a wide charging/discharging voltage range of 728–936 V, it employs Grade-A LFP cells and offers a 10‑year warranty. The system operates reliably from -20℃ to 60℃ and complies with IEC/EN safety standards. Its compact integrated design (1300×1300×2340 mm without inverter) facilitates easy installation. It is ideal for microgrids, backup power, off-grid peak shaving, virtual power plants (VPP), and other scenarios, helping industrial parks, office buildings, shopping malls, and charging stations achieve cost efficiency and green energy transition.
Product Description
-
High Capacity & Reliability: Nominal capacity of 261.2 kWh with guaranteed minimum capacity; Grade-A LFP cells ensure long cycle life and excellent safety.
-
Wide Voltage & Temperature Range: Charging voltage 728–936 V, load voltage same range; operating temperature -20~60℃, storage -30~45℃, suitable for harsh environments.
-
Efficient Charging/Discharging: Standard voltage 832 V, charging current up to 157 A, supports high-power charge/discharge to meet peak C&I loads.
-
Full Safety Certifications: Certified to IEC/EN 62109-1, IEC/EN 62109-2, and IEC/EN 61000-6-1, ensuring electrical safety and EMC compliance.
-
Versatile Applications: Perfect for microgrids, backup power, off-grid peak shaving, self-consumption, VPP, and integration with small C&I storage systems.
-
Robust & Durable Design: Net weight 3,500 kg, dimensions 1300×1300×2340 mm (without inverter); sturdy construction for long-term indoor or outdoor deployment.
-
Extended Warranty: 10‑year product warranty demonstrates confidence in cell and system quality, reducing total cost of ownership.
-
Customizable: Supports tailored modifications to meet specific project voltage, capacity, or size requirements.
FAQ
Q1: What is the cycle life of this system?
A1: Using Grade-A LFP cells, the cycle life is ≥6,000 cycles at 80% DOD and room temperature, depending on operating conditions and charging/discharging strategies.
Q2: Does the system support both grid-tied and off-grid operation?
A2: Yes, it is designed to support both modes with seamless switching via an inverter, suitable for backup power and off-grid peak shaving.
Q3: What are the basic installation requirements?
A3: A flat concrete floor, good ventilation, ambient temperature between -20~60℃, and appropriate distribution cabinets and communication interfaces (Modbus, CAN, etc.) are needed. We provide installation guidance.
Q4: What is the lead time?
A4: Standard lead time is about 30‑45 days, depending on order quantity and customization. Expedited delivery can be negotiated.
Q5: How does the warranty work?
A5: We offer a 10‑year warranty covering free repair or replacement for quality-related defects, excluding misuse or out-of-spec operation.
Q6: Do you provide local technical support?
A6: Yes, we have service centers in major regions offering remote diagnostics, on-site maintenance, and training for rapid response.
Q7: What is the ingress protection (IP) rating?
A7: The standard rating is IP54 (upgradeable), providing effective dust and splash protection for outdoor or semi-outdoor installation.
Why Choose US？
-
Premium Cell Quality: Strictly selected Grade-A LFP cells ensure superior safety and longevity from the core.
-
International Certifications: All products pass rigorous IEC/EN standards, meeting global market access requirements.
-
10‑Year Long Warranty: Far exceeding industry average, reducing your operational risk and total cost of ownership.
-
Full-Scenario Adaptability: Proven in industrial parks, office buildings, charging stations, microgrids, and more, offering flexible energy storage solutions.
-
R&D & Customization Expertise: Strong engineering team supports bespoke designs and rapid response to special voltage, capacity, or dimensional needs.
-
Comprehensive After-Sales Network: Technical support teams across key markets, 24/7 online service to ensure system stability and peace of mind.
Product Specification Sheet
| Item | Parameter |
|---|---|
| Place of Origin | Shenzhen, Guangdong, China |
| Battery Type | Lithium Iron Phosphate (LFP) |
| Model | GSL-BESS-261K |
| Rated Capacity | 1,000,000 mAh |
| Customization | Yes |
| Standard Voltage | 832 V |
| Charging Current | 157 A |
| Dimensions (without inverter) | 1300 × 1300 × 2340 mm |
| Application Type | Backup Power Supply |
| Certifications | IEC/EN 62109-1, IEC/EN 62109-2, IEC/EN 61000-6-1 |
| Applicable Product Type | Small Commercial & Industrial Energy Storage |
| Overall Dimensions | 1300 × 1300 × 2340 mm |
| Rechargeable | Yes |
| Standard Capacity | 261 kWh |
| Material | Lithium Iron Phosphate (LFP) |
| Product Name | GSL-BESS Commercial & Industrial Energy Storage System |
| Charging Voltage | 728 – 936 V |
| Storage Temperature | -30 ~ 45 ℃ |
| Operating Temperature | -20 ~ 60 ℃ |
| Net Weight | 3,500 kg (3,500,000 g) |
| Application Scope | Microgrids, Backup Power, Off-grid Peak Shaving, Self-supply, Virtual Power Plants, etc. |
| Minimum Capacity | 261.2 kWh |
| Warranty Period | 10 Years |
| Cell Standard | Grade-A Cells |
| Factory Voltage | 832 V |
| Load Voltage | 728 – 936 V |
| Chargeable | Yes |
| Nominal Capacity | 261.2 kWh |
| Typical Use | Commercial & industrial energy storage for industrial parks, office buildings, shopping malls, charging stations, and similar C&I scenarios |
