Wall Mount EV Charger Wallbox Charging Pile IP65
MOQ: 1 Pcs (Min. Order)
| Output current | 32A |
| Input voltage | 400V ± 15% |
| Operating temperature | -25℃ ~ +60℃ |
| Output power | 22 kilowatts |
| Interface standards | IEC 62196 (Type 2)/GBT |
|
Housing material
|
PC + ABS |
| IP Rating | IP 65 |
| Lens Beamangle | 60° |
| Warranty | 3 years |
Please Send Inquiry, we'll get back to email you in 12 hours.
Description
| Output current | 32A |
| Input voltage | 400V ± 15% |
| Operating temperature | -25℃ ~ +60℃ |
| Output power | 22 kilowatts |
| Interface standards | IEC 62196 (Type 2)/GBT |
|
Housing material
|
PC + ABS |
| IP Rating | IP 65 |
| Lens Beamangle | 60° |
| Warranty | 3 years |
- Safe charging of electric vehicles and plug-in hybrids
- Exceptionally flexible with max. 22 kW charging power
- RFID function with master card and two user cards
- Built-in DC fault current detection
- Attractive design and high impact resistance class (IK10)
- Robust safety features: the charger is made of high-quality materials and meets TUV safety certification standards. It provides comprehensive protection through undervoltage protection, short circuit protection, leakage protection, lightning protection, overload protection and temperature protection
- WIFI & APP CONTROL The charging station allows you to program the charging times and monitor the charging status via WiFi. With the app, charging times and cycles can be managed and optimised to benefit from low electricity rates
- FLEXIBLE USE The charger can be installed on walls or poles and is equipped with a 5 meter charging cable to allow for more flexible installation options and longer charging distances
- Commercial Certifications The AC charging station meets UKCA and CE certifications and is suitable for installation in commercial environments such as shopping malls and public parking lots
- SAFETY INDICATORS AND EMERGENCY STOP BUTTON The status indicators on the charging station help to detect the charge status and possible errors. An emergency stop button allows you to stop charging immediately in an emergency
