Photovoltaic Module 550W 182MM
MOQ: 1 Pcs (Min. Order)
| Types | BSM525M10- 72HPH | BSM530M10-72HPH | BSM535M10-72HPH | BSM540M10-72HPH | BSM545M10-72HPH | BSM550M10-72HPH |
| Rated maximum power (Pmax) [w] | 525 | 530 | 535 | 540 | 545 | 550 |
| Open Circuit Voltage (Voc) [M] | 49.15 | 49.3 | 49.45 | 49.6 | 49.75 | 49.9 |
| Maximum Power Voltage (Vmp) [V] | 41.15 | 41.31 | 41.37 | 41.64 | 41.8 | 41.96 |
| Short Circuit (lsc) (A) | 13.65 | 13.72 | 13.79 | 13.86 | 13.93 | 14 |
| Maximum Power Current (lmp) [A] | 12.76 | 12.83 | 12.9 | 12.97 | 13.04 | 13.11 |
| Module efficiency [%] | 20.3 | 20.5 | 20.7 | 20.9 | 21.1 | 21.3 |
| Power tolerance | 0~+5W |
Please Send Inquiry, we'll get back to email you in 12 hours.
Description
| Types | BSM525M10- 72HPH | BSM530M10-72HPH | BSM535M10-72HPH | BSM540M10-72HPH | BSM545M10-72HPH | BSM550M10-72HPH |
| Rated maximum power (Pmax) [w] | 525 | 530 | 535 | 540 | 545 | 550 |
| Open Circuit Voltage (Voc) [M] | 49.15 | 49.3 | 49.45 | 49.6 | 49.75 | 49.9 |
| Maximum Power Voltage (Vmp) [V] | 41.15 | 41.31 | 41.37 | 41.64 | 41.8 | 41.96 |
| Short Circuit (lsc) (A) | 13.65 | 13.72 | 13.79 | 13.86 | 13.93 | 14 |
| Maximum Power Current (lmp) [A] | 12.76 | 12.83 | 12.9 | 12.97 | 13.04 | 13.11 |
| Module efficiency [%] | 20.3 | 20.5 | 20.7 | 20.9 | 21.1 | 21.3 |
| Power tolerance | 0~+5W |
Significantly reduce your electricity bill with clean, reliable solar energy. Our high-efficiency solar panels utilize advanced technology to continuously generate power even in low-light conditions, ensuring your home gets the most out of its energy. Investing in sunlight is investing in a smarter, more sustainable future.
- Significant Energy Savings: Harness free solar energy to significantly reduce your monthly electricity bill.
- Efficient and Durable: Leading-edge photovoltaic conversion efficiency ensures stable power output for over 25 years.
- Low-Light Power Generation: Optimized design ensures excellent performance in early mornings, evenings, and on cloudy days.
- Rugged and Reliable: Wind- and hail-resistant, built to last, even in the elements.
- Green Choice: Reduce your carbon footprint and contribute to protecting the planet.
