High Quality Square Lithium Cell Laser Welding Screw Locking Automatic Production Line for Home Energy Storage Utility ESS Battery Pack Assembly
This production line is specifically designed for the PACK assembly of prismatic aluminum-case lithium cells, integrating laser welding and automatic screw locking as core processes. It covers the entire workflow from cell loading, terminal cleaning, and laser welding to busbar tightening, insulation testing, and module offloading. Ideal for high-volume, high-consistency production of residential energy storage, home battery systems, and C&I containerized ESS projects.
| Attribute | Value | Attribute | Value |
|---|---|---|---|
| Item No. | SW-F1000 | Country of Origin | China |
| Application | 18650/26650/21700 Lithium Battery Modules | Scope of Application | Factory |
| Worktable Type | PACK production line | Authorized Private Label Available | Yes |
Core Processes
· Laser Welding System：Fiber laser source with galvanometer scanning or flying optics enables low-spatter, deep-penetration welding on busbars and terminals. Ensures stable tensile strength and minimal heat-affected zone.
· Automatic Screw Locking Unit：Multi-axis servo-controlled screw drivers with torque accuracy within ±3%, assisted by vision-guided positioning to prevent cross-threading or insufficient torque, guaranteeing reliable busbar connections.
· Intelligent Conveying & Positioning：Speed chain or roller conveyor combined with precision fixtures ensures accurate cell spacing, compatible with various module sizes, with changeover time ≤ 30 minutes.
Technical Advantages
· High Yield Guarantee：In-line CCD inspection and weld quality monitoring system provides real-time feedback. Welding yield ≥99.5%, screw locking yield ≥99.8%.
· Full Traceability：Each cell is assigned a unique QR code; all production data (welding parameters, torque values, voltage & IR) are uploaded to the MES system for full lifecycle traceability.
· Modular Design：Each station operates independently with individual start/stop controls, easy maintenance, and supports future flexible capacity expansion.
Why Choose Us
· 10+ years in lithium battery automation, with 50+ ESS PACK lines delivered globally
· One-stop service from solution design, simulation, installation & commissioning to on-site after-sales support
· Remote operation & diagnostic support available, 7×24 technical response
Product Attributes
| Attribute | Value | Attribute | Value |
|---|---|---|---|
| Item No. | SW-F1000 | Country of Origin | China |
| Application | 18650/26650/21700 Lithium Battery Modules | Scope of Application | Factory |
| Worktable Type | PACK production line | Authorized Private Label Available | Yes |
